Figure 1.4 Instrument Left Side With 3 Ports
Figure 1.5 Instrument Left Side With 2 Ports
Waste Port
Waste tank drains
through this port.
Supply Port
Supply tank is filled through this port;
can also be used to connect external
supply tank.
Warning: The water from the waste
ports may contain ethanol and
residual DNA sample. It must be
disposed of properly according to
local regulations.
Vac Waste Port
Vacuum tank
drains through
this port.
Caution: Connect the supply port
to a Type 1, >18.2 MΩ water source
only.
Supply Port
Supply tank is filled through this port; can also
be used to connect external supply tank.
Vac Waste Port
Vacuum tank drains
through this port.
Caution: Connect the supply port to
a Type 1, >18.2 MΩ water source
only.
