192 1290 Infinity Quaternary Pump User Manual
9 Maintenance
Install the Pump Head Assembly
3
Connect the capillary from the pressure sensor to the
pump head outlet filter.
4 Install the seal wash tubings to the seal wash
connectors.
3UHVVXUHVHQVRU
2XWOHWILOWHU
