Agilent Technologies 1290 infinity - Initialization Mode Selection

1290 Infinity Quaternary Pump User Manual 271
LAN Configuration
13
Initialization Mode Selection
Initialization Mode Selection
The following initialization (init) modes are selectable:
Using Stored
When initialization mode Using Stored is selected, the parameters are taken
from the non-volatile memory of the module. The TCP/IP connection will be
established using these parameters. The parameters were configured
previously by one of the described methods.
Figure 37 Using Stored (Principle)
Tab le 1 5 Initialization Mode Switches
SW 6SW 7SW 8Init Mode
OFF ON OFF Using Stored
OFF ON ON Using Default
ON OFF OFF
DHCP
1
1
Requires firmware B.06.40 or above. Modules without LAN on board, see G1369C LAN Interface Card
1RQ9RODWLOH
5$0
6WRUHG
3DUDPHWHU
$FWLYH
3DUDPHWHU
