1290 Infinity Quaternary Pump User Manual 229
Parts and Materials
10
Leak Parts
Leak Parts
Figure 29 Leak parts
Item p/n Description
1 5041-8389 Leak funnel holder
2 5041-8388 Leak funnel
3 5062-2463 Corrugated tubing, PP, 6.5 mm id, 5 m
4 G1361-47100 Sealing lip
5 5042-9922 Leak panel
6 G4280-40016 Power Switch Coupler ZL
7 5041-8381 Power switch button
