202 1290 Infinity Quaternary Pump User Manual
9 Maintenance
Removing the Inline Filter
Removing the Inline Filter
Tools required p/n Description
8710-0510 Open-end wrench 1/4 — 5/16 inch
Parts required p/n Description
5067-5416 Capillary ST 0.17 x 120 mm, SLV/SV
1 Remove the capillaries from the Multi Purpose Valve to
the inline filter.
2 Remove the clamp with the inline filter (if installed).
&ODPS
,QOLQHILOWHU
