Agilent Technologies 1290 infinity - Flushing the Filter

1290 Infinity Quaternary Pump User Manual 73
Using the Module
4
Flushing the Filter
Flushing the Filter
For highest performance and robustness, the 1290 Infinity Quaternary Pump
uses 3 solvent filters:
1 Solvent inlet filter, 20 m pore size (5041-2168) as part of Bottle Head
Assembly (G4220-60007) have a large pore size of about 20 m and filter
out particles before they reach the pump.
2 An outlet filter (average pore size 5 m; Outlet filter Quaternary
Pump/Flexible Pump (G4204-60004)) between pump head and pressure
sensor filters out particles which may be created in the pump by wear of
piston or wash seals.
This filter can be replaced as required.
3 An optional inline filter connected to the Multi Purpose Valve with a small
pore size of about 0.3 m ( Inline Filter Assembly (5067-5407)).
This filter can be flushed using the graphical user interface or replaced as
required.
6ROYHQWLQOHWILOWHU
