Installing the Pump
Installing the Pump
1 Place the module on the bench in a horizontal position.
2 Ensure the power switch on the front of the module is OFF (switch stands
out).
Figure 13 Front view of the quaternary pump
Parts required # Description
1Pump
1 Power cord
1 Agilent Control Software and/or Instant Pilot G4208
Preparations Locate bench space
Provide power connections
Unpack the pump
6WDWXVLQGLFDWRU
3RZHUVZLWFK
6HULDOQXPEHU
