206 1290 Infinity Quaternary Pump User Manual
9 Maintenance
Replacing Parts of the Inline Filter
5
Put the inline filter to the clamp and install its capillaries.
The integrated capillary is connected to port 5 of the
Multi Purpose Valve. The removable capillary is
connected to port 8.
3RUW
3RUW
,QWHJUDWHG
FDSLOODU\
5HPRYDEOH
FDSLOODU\
