1290 Infinity Quaternary Pump User Manual 65
Using the Module
4
Setting up the Pump with the Instrument Control Interface
Context Menu
The context menu of the dashboard panel contains the following commands:
Control Displays the pump's Control dialog box.
Method Displays the pump's Method Setup dialog box.
Set Error Method Sets the method that is loaded if an error occurs to the
method that is currently available in the hardware.
Identify Device Causes the LED on the front of the module to blink for a few
seconds.
Switch Pump On/Off Toggles the status of the pump, on or off.
Bottle Fillings Displays the Bottle Fillings dialog box.
Purge On/Off Allows you to control the purging of the system.
Prime On/Off Allows you to prime the pump heads for initially drawing
solvent.
Conditioning On/Off Allows you to switch pump conditioning on and off. The
conditioning function is useful for removing small air bubbles
inside the pump flow path.
Flush Filter On/Off Allows you to flush a clogged inline filter, which is connected
to the Multi Purpose Valve, see “Filter Flush Mode” on
page 17. Use the pump self-test for checking the filter back
pressure. Do not use this option if no filter is installed!
