78 1290 Infinity Quaternary Pump User Manual
4 Using the Module
Solvent Information
Materials in Flow Path
Following materials are used in the flow path of this module:
Part Materials
Degasser chamber TFE/PDD copolymer, PFA (internal tubings); PEEK (inlets); FEP
(tubings); ETFE (fittings)
Ultra clean tubings
1
1
Ultra clean tubings are available for the use with high-end MS detectors. They are also compatible
to THF.
PFA (tubings), PEEK (fittings)
Microfluidic structures
2
2
Inlet Weaver, Jet Weaver, Heat Exchanger
SST
MCGV PEEK, FEP, PFA, Al
2
O
3
-based ceramic, ruby, sapphire, SST
Passive inlet valve SST, gold, ruby, ZrO
2
-based ceramic, tantalum
Outlet valve SST, gold, ruby, ZrO
2
-based ceramic, tantalum
Pump head SST
Pistons ZrO
2
-based ceramic
Piston/wash seals UHMW-PE, SST
Pressure sensor SST
Multi Purpose Valve Polyimide, SST, DLC
