Installing the Autosampler
Site Requirements
Power Cords
Your autosampler is delivered with a power cord which matches the wall
socket of your particular country or region. The plug on the power cord
which connects to the rear of the instrument is identical for all types of
power cord.
WARNING Never operate your instrumentation from a power outlet that has no
ground connection. Never use a power cord other than the power cord
designed for your region.
WARNING Never use cables other than the ones supplied by Agilent Technologies
to ensure proper functionality and compliance with safety or EMC
regulations.
Bench Space
The autosampler dimensions and weight (see Table 1) allow the
instrument to be placed on almost any laboratory bench. The instrument
requires an additional 2.5 cm (1.0 inch) of space on either side, and
approximately 8 cm (3.1 inches) at the rear for the circulation of air, and
room for electrical connections. Ensure the autosampler is installed in a
horizontal position.
The thermostatted autosampler dimensions and weight (see ) allow the
instrument to be placed on almost any laboratory bench. The instrument
requires an additional 25 cm (10 inches) of space on either side for the
circulation of air, and approximately 8 cm (3.1 inches) at the rear for
electrical connections. Ensure the autosampler is installed in a level
position.
If a complete Agilent 1100 Series system is to be installed on the bench,
make sure that the bench is designed to carry the weight of all the
modules. For a complete system including the thermostatted autosampler
it is recommended to position the modules in two stacks, see “Optimizing
the Stack Configuration” on page 22. Make sure that in this configuration
there is 25 cm (10 inches) space on either side of the thermostatted
autosampler for the circulation of air.
