Getting Started
i3070 Series 5i Help 1-5
Figure 1-2 Zone 1 – Front View
PDU On/Off Switch
Air Regulator
Controller
System Card
DUT Power Supplies
Zone 1 Conveyor
Crank for Conveyor Width
Adjustment
