1-6 i3070 Series 5i Help
Getting Started
Figure 1-3 Zone 2 – Front View
Figure 1-4 Rear View
Press Assembly
PLC
Drawer
Card Cage
Anti-Rotation Guide Bar
Zone 2 Conveyor
Manual Control Panel
Electrical Panel
PDU
MPU
Power Outlets
Guided Probe
Debug Ports
RJ45 Coupler
Mains Disconnect Switch
with Cradle
