7-26 i3070 Series 5i Help
Replacement Procedures
Update config Files
The power supply connections must be declared in the system and
standard
config files.
Example 7-1
bank 2
module 2
…………
supplies ps6751 5 to 8 asru channels 1 to 4
! supplies hp6634 19 asru channels 5
! supplies hp6634 20 asru channels 6
ports ext3, ext4
end module
module 3
…………
supplies ps6751 1 to 4 asru channels 1 to 4
! supplies hp6634 17 asru channels 5
! supplies hp6634 18 asru channels 6
ports ext1, ext2
end module
end bank
