Agilent Technologies Medalist i3070 5i Series - Page 116

7-28 i3070 Series 5i Help
3 Open the rear door.
4 Loosen the two screws on the set collar and push the set collar against
the linear bearing. Tighten the screws on the set collar.
Do the same for the other set collar.
Linear Bearings
Set Collar
Set Collar
