Troubleshooting
i3070 Series 5i Help 6-19
Figure 6-8 Zone 2 Sensors
Right Limit Sensor
PHS-25
Origin Sensor
PHS-24
Left Limit Sensor
PHS-26
Conveyor Conveyor
Conveyor
Zone 2 Inlet Sensor
PHS-4
Zone 2 Stopper Slow Sensor PHS-5
Zone 2 Stopper Sensor PHS-6
Zone 2 Exit Sensor
PHS-7
