6 N9310A User’s Guide
1Overview
12 LF Out connector This BNC connector outputs the low
frequency (LF) signal whenever you set the > LF OUT to
on. The LF output is capable of driving 3 Vpeak (nominal)
into a 50 ohm load.
13 Numeric Keypad includes 0 through 9, a decimal point and a
backspace key. The backspace hardkey also enables you to
specify a negative value. When specifying a negative numeric
value, enter a negative sign prior to entering the numeric
value.
14 Standby Switch switches on all functions of the signal
generator. When pressing this key to switch the signal
generator Off, the signal generator deactivate all the
functions but still remains connected to the line power,
while the line power is supplied to some internal circuits.
15 Switch On LED This green LED lights when the signal
generator is switched on.
16 Standby LED This orange LED lights when the signal
generator is connected to the line power.
17 Remote LED This LED lights when the signal generator is
remotely controlled by a PC via the USB host interface on
the rear panel.
18 USB Device Connector provides a connection between external
USB devices and the signal generator, such as a USB
memory stick.
LF Out
