24 N9310A User’s Guide
2 Getting Started
Some Tips
Refer to the following hints to set up the signal generator for
your preference. For more detailed description, see
“Utility” on page 81.
• Set the screen saver on by pressing
> Screen Saver> On
With the screen saver set to On, the display light turns off
after 15 minutes with no input from the front panel. The
display light turns on when pressing any front panel key.
• Select a display style by pressing
> Display Style
• Toggle the phase noise mode by pressing
> Opti. F Noise> Normal/ResFM Opt.
• Save the current configures for your frequent use to
either local memory or an external USB memory
• Connect and set an external reference by pressing
> Ref Setups
• Connect an external display monitor to the VGA
connector for the education projects or other needs.
Enable an option
You are required to enter the option license key to enable
the option. Contact your nearest Agilent Office for
purchasing a license. Refer to the following steps to enable
the I/Q modulator (option 001):
1 Press hardkey
2 Press License key softkey
3 Enter the license and the option will be enabled immediately
Utility
Utility
NOTE
The display style and the screen saver are persistent state, pressing
hardkey will not affect these settings.
Preset
Utility
Utility
Utility
