36 N9310A User’s Guide
3Using Functions
Generating an RF Sweep
Assume you are going to generate an RF sweep with the fol-
lowing settings:
• frequency range from 1 GHz to 2 GHz, at a level of 0
dBm
• nine sweep points and 50 ms dwell time at each point
Refer to the following procedures to configure and generate
an RF sweep:
1 Press
hardkey
2 Press
> 0 > dBm
This step sets the RF sweep output level at 0 dBm.
3 Press hardkey
This step opens the sweep submenus.
4 Press Step Sweep softkey
This step opens a submenu for step sweep configurations.
5 Press RF Start > 1 > GHz
This step sets the start frequency of the sweep to 1 GHz.
6 Press RF Stop > 2 > GHz
This step sets the stop frequency of the sweep to 2 GHz.
7 Press # Points > 9 > Enter
This step sets the number of sweep points to nine.
8 Press More(1/2) > Step Dwell > 50 > ms
This step sets the dwell time at each point to 50 ms.
9 Press hardkey to enable the RF output.
The annunciator changes from to .
Preset
Amplitude
Sweep
RF
On/Off
