Generating an LF Sweep
Assume you are going to generate an LF sweep with the fol-
lowing settings:
• frequency range from 10 to 60 kHz, at a level of 500 mV
• six sweep points and 50 ms dwell time at each point
Refer to the following procedures to configure and generate
an LF sweep:
1 Press
hardkey
2 Press hardkey
3 Press Step Sweep softkey
4 Press LF Start > 10 > kHz
5 Press LF Stop > 60 > kHz
6 Press # Points > 6 > Enter
7 Press Step Dwell > 50 > ms
8 Press Return > Sweep State > LF
This initiates the LF sweep output immediately via the LF
OUT connector. A SWEEP annunciator displays for the
duration of the sweep.
For more information about the sweep settings, please refer
to “Sweep” on page 73.
NOTE
Pressing sets the sweep/point trigger to Immediate and the LF
output amplitude to 500 mV. The following procedures leave out the steps
that set up the sweep/point trigger and the LF output amplitude.
Preset
Preset
Sweep
To Next Page
