18 N9310A User’s Guide
2 Getting Started
Electrical Requirements
The signal generator has an auto- ranging line voltage input.
The available AC power source must meet the following con-
ditions:
Connecting the AC Power Cord
This is a Safety Class I Product provided with a protective
earth ground incorporated into the power cord. The front
panel switch is only a standby switch; it is not a power
switch. The AC power cord is the disconnecting device that
disconnects the signal generator mains circuits from the
mains supply. Alternatively, The rear panel switch or circuit
breaker may also be used as a disconnecting device.
Perform the following steps to connect the AC power cord:
✔ Ensure that the power cord is not damaged.
✔ Install the signal generator so that you can easily reach
the AC power cord or circuit breaker.
✔ Insert the main plug into a socket outlet provided with a
protective earth grounding.
Voltage: 100~240 volts nominal
Frequency:50/60 Hz nominal
Power: 100 watts maximum
