Key Reference 4
N9310A User’s Guide 57
Amplitude
Pressing hardkey allows you to modify the RF output
power level. Amplitude becomes the active function and the
active entry area of the display shows the current value.
The calibrated power range is –127 to 13 dBm (+20 dBm
settable). The minimum increment allowed is 0.1 dB. The
amplitude area of the display always shows the current RF
output power except when an amplitude sweep is in process.
• Default value: –127.0 dBm
It also allows you to modify the RF output power level using
the following scales:
Range Minimum increment
–127.0 to +13.0 dBm, (max. +20 dBm settable) 0.1 dB
–80.0 to +60.0 dBmV, (max. +67 dBmV settable) 0.1 dB
–20.0 to +120.0 dBμV, (max. +127 dBμV settable) 0.1 dB
0.0001 to 1000.0 mV, (max. 2238.8 mV settable) 0.1 mV
0.1 to 1000000.0 μV, (max. 2238800 μV settable) 0.1 μV ( Ampl < 999.9 μV)
100 μV (Ampl >
1000.0 μV)
Amplitude
To Next Page
