Alcatel-Lucent 7210 SAS M - Figure 22: Shared Risk Link Groups

Advanced MPLS/RSVP Features
Page 72 7210 SAS M, T, X, R6, Mxp MPLS Configura-
tion Guide
Figure 22: Shared Risk Link Groups
This feature is supported on OSPF and IS-IS interfaces on which RSVP is enabled.
SRLG 1
SRLG 2
Primary Path (FRR, node protection)
Bypass tunnel taking SRLG into account
Secondary path taking SRLG into account
Fig_33
