Alcatel-Lucent 7210 SAS M User Manual

Common Configuration Tasks
Page 84 7210 SAS M, T, X, R6, Mxp MPLS Configura-
tion Guide
Configuring MPLS Components
Use the MPLS and RSVP CLI syntax displayed below for:
• Configuring Global MPLS Parameters on page 84
• Configuring an MPLS Interface on page 85
• Configuring MPLS Paths on page 86
• Configuring an MPLS LSP on page 87
• Configuring a Static LSP on page 88
• Configuring RSVP Parameters on page 91
• Configuring RSVP Message Pacing Parameters on page 92
Configuring Global MPLS Parameters
Admin groups can signify link colors, such as red, yellow, or green. MPLS interfaces
advertise the link colors it supports. CSPF uses the information when paths are computed for
constrained-based LSPs. CSPF must be enabled in order for admin groups to be relevant.
To configure MPLS admin-group parameters, enter the following commands:
CLI Syntax: mpls
admin-group group-name group-value
frr-object
resignal-timer minutes
The following displays an admin group configuration example:
A:ALA-1>config>router>mpls# info
----------------------------------------------
resignal-timer 500
admin-group "green" 15
admin-group "yellow" 20
admin-group "red" 25
...
----------------------------------------------
A:ALA-1>config>router>mpls#
