Page 330 7450 ESS MPLS Guide
Label Description
Auto BW
Enabled – Auto-bandwidth adjustment is configured on this LSP.
AB OpState
Up – Auto-bandwidth is operationally enabled on this LSP
Down – Auto-bandwidth is operationally disabled on this LSP
Auto BW Min
The minimum bandwidth of the LSP that auto-bandwidth can request
(in Mbps).
Auto BW Max
The maximum bandwidth of the LSP that auto-bandwidth can
request (in Mbps).
AB Up Thresh
The percent threshold for increasing LSP bandwidth.
AB Down Thresh
The percent threshold for decreasing LSP bandwidth.
AB Up BW
The absolute bandwidth threshold for increasing LSP bandwidth (in
Mbps).
AB Down BW
The absolute bandwidth threshold for decreasing LSP bandwidth (in
Mbps).
AB Coll Intv
The auto-bandwidth collection interval.
AB Adj Mul
The adjust-multiplier for this LSP (may be configured or inherited).
AB Samp Mul
The sample-multiplier for this LSP (may be configured or inherited).
AB Adj Time
The adjust-multiplier times the collection-interval (in Mins).
AB Sample Time
The sample-multiplier times the collection-interval (in Mins).
AB Adj Cnt
The adjust count (number of whole collection intervals since the start
of the current adjust interval).
AB Samp Cnt
The sample count (number of whole collection intervals since the
start of the current sample interval).
AB Last Adj
The system time of the last auto-bandwidth adjustment.
AB Next Adj
The approximate remaining time in the current adjust interval
(adjust-multiplier – adjust count) times the collection interval (in
Mins). This overstates the actual remaining time because the elapsed
time in the current collection interval is not accounted for.
AB Adj Cause
The cause of the last auto-bandwidth adjustment:
• none – no adjustment has occurred
• manual
• adj-count
•overflow
