USB connector: we recommend a USB 3.0 port (USB 2.0 or 1.0 port can reduce
performance).
We recommend using the latest version of audio applications or web browser.
5.1.1.2 Connect your computer to your desk phone
You can use a USB-A or USB-C connectors of the DeskPhone to connect the PC. A stand-alone USB
cable is not provided with your set.
Configure your desk phone to use it as an audio hub.
The phone is in idle state.
Press the Menu soft key to access the Main Menu.
Use up-down and 'ok' navigation keys to select:
Basic Setting
.
Use up-down and 'ok' navigation keys to select:
Usb
.
Select the USB port you are using to connect the PC (USB-A, USB-C).
Create the programmable key:
Audio Hub
(see chapter: Programmable keys).
The programmable key allows you to control the audio on the phone (pause, play).
As long as the PC is not connected, the following icon is displayed in front of the
programmable key and on the status bar: .
Connect your computer to the USB-A or USB-C connector of your desk phone with the USB
cable (not provided). The phone is recognized as a sound device on computer (for example
'Echo cancelling speakerphone' with Windows). The following icon is displayed in front of
the programmable key and on the status bar: .
5.1.1.3 Set the default audio device for Windows
In most cases, your desk phone is ready to be used when connected to your computer. However, it
is sometimes necessary to manually configure the playback and recording default device. The
configuration depends on the operating system of the
connected computer. Consult the user manual of the
operating system of your computer.
5.1.1.3.1 Windows
Open the sound control panel from the Windows
configuration panel or the sound icon in the
Windows notification area.
In the 'Playback' tab: Select your desk phone as
