Publication 1756-UM523F-EN-P - December 2006
Update Modules and Redundant Systems 141
5. Disqualify the secondary chassis, A. Click Configuration.
B. Set Auto-Synchronization to Never.
C. Choose Apply and then Yes.
D. Click Synchronization.
F. Click OK.
6. Update the SRM module in the secondary
chassis.
A. Start the ControlFLASH firmware update tool.
B. Update the 1757-SRM module in the secondary chassis.
7. Synchronize the chassis. A. Go to the SRM configuration tool.
B. Click Synchronize Secondary and then Yes.
Action Details
E. Click Disqualify Secondary and then Yes.
The secondary chassis is
disqualified.
The chassis are synchronized.
