164 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Appendix A Specifications
Output group to
backplane isolation
Verified by one of the
following dielectric
tests: 1836V AC for 1 s
or 2596V DC for 1 s.
265V AC working
voltage (IEC Class 2
reinforced insulation)
Verified by one of the following dielectric tests:
1200V AC for 1 s or 1697V DC for 1 s.
75V DC working voltage (IEC Class 2 reinforced
insulation)
Verified by one of the following dielectric tests:
1200V AC for 2 s or 1697V DC for 2 s.
75V DC working voltage (IEC Class 2 reinforced
insulation)
Output group to output
group isolation
Verified by one of the
following dielectric
tests: 1836V AC for 1 s
or 2596V DC for 1 s.
265V AC working
voltage (IEC Class 2
reinforced insulation)
Not applicable Verified by one of the following dielectric tests:
1200V AC for 2 s or 1697V DC for 2 s.
75V DC working voltage (IEC Class 2 reinforced
insulation)
Vendor I.D. code 1
Product type code 7
Product code 119 101 1 03 100 102
Output Specifications
Specification 1762-OA8 1762-OB8 1762-OB16 1762-OB32T 1762-OV32T
Output Specifications
Specification 1762-OW8 1762-OW16 1762-OX6I 1762-IQ8OW6
Shipping weight, approx.
(with carton)
228 g (0.50 lbs.) 285 g (0.63 lbs.) 220 g (0.485 lbs) 280 g (0.62 lbs.)
Voltage category AC/DC normally open
relay
AC/DC normally open
relay
AC/DC Type C Relay AC/DC normally open
relay
Operating voltage range 5…265V AC
5…125V DC
5…265V AC
5…125V DC
5…265V AC
5…125V DC
5…265V AC
5…125V DC
Number of outputs 8 16 6 6
Bus current draw, max. 80 mA at 5V DC
(0.40W)
90 mA at 24V DC
(2.16W)
140 mA at 5V DC
(0.70W)
(1)
180 mA at 24V DC
(4.32W)
(1)
110 mA at 5V DC
(0.55W)
110 mA at 24V DC
(2.64W)
110 mA at 5V DC
80 mA at 24V DC
Heat dissipation, max. 2.9 W 6.1 W
(1)
2.8 W 5.0 W at 30V DC
4.4 W at 26.4V DC
(The Watts per point,
plus the minimum W,
with all points
energized.)
Signal delay, max. –
resistive load
On Delay: 10 ms
Off Delay: 10 ms
On Delay: 10 ms
Off Delay: 10 ms
On Delay: 10 ms (max)
6 ms (typical)
Off Delay: 20 ms (max)
12 ms (typical)
On-delay: 10 ms (max)
Off-delay: 10 ms (max)
Off-state leakage, max. 0 mA 0 mA 0 mA 0 mA
On-state current, min. 10 mA 10 mA 100 mA 10 mA
On-state voltage drop,
max.
Not Applicable
Continuous current per
point, max.
2.5 A (Also see “Relay Contact Ratings” on page
165.)
7 A (Also see “Relay
Contact Ratings” on
page 165.)
2.5 A (Also see “Relay
Contact Ratings” on
page 165.)
