Allen-Bradley MicroLogix 1400 User Manual

Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 249
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
Table 2.1
Word Offset Default Variation for the following Objects Group and Standard
Default Variation
Alternate Default
Variations
0 Binary Input Static Object g1v1 v2
1 Binary Input Change Object g2v3 v1, v2
2 Binary Output Static Object g10v2 none
3 Reserved -
4 Double Bit Binary Input Static Object g3v1 v2
5 Double Bit Binary Input Change Object g4v3 v1, v2
6 16-bit Counter Static Object g20v6 v2
7 32-bit Counter Static Object g20v5 v1
8 Frozen 16-bit Counter Static Object g21v10 v2, v6
9 Frozen 32-bit Counter Static Object g21v9 v1, v5
10 16-bit Counter Change Object g22v2 none
11 32-bit Counter Change Object g22v1 none
12 Frozen 16-bit Counter Change Object g23v2 v6
13 Frozen 32-bit Counter Change Object g23v1 v5
14 16-bit Analog Input Static Object g30v4 v2
15 32-bit Analog Input Static Object g30v3 v1
16 Short Floating Point Analog Input Static Object g30v5 none
17 16-bit Analog Input Change Object g32v2 v4
18 32-bit Analog Input Change Object g32v1 v3
19 Short Floating Point Analog Input Change Object g32v5 v7
20 16-bit Analog Output Static Object g40v2 none
21 32-bit Analog Output Static Object g40v1 none
22 Short Floating Point Analog Output Static Object g40v3 none
23 Reserved -
24 Reserved -
25 Reserved -
26 Small BCD Object g101v1 none
27 Reserved -
28 Reserved -
29 Reserved -
30 Reserved -
31 Reserved -

Allen-Bradley MicroLogix 1400 Specifications

General

Processor	32-bit
Expansion Modules	Up to 7 expansion I/O modules
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Communication Ports	Ethernet, RS-232/RS-485 combo port
Controller Type	Programmable Logic Controller (PLC)
Series	MicroLogix
Digital Outputs	12
Analog Inputs	6 (embedded)
Analog Outputs	2 (embedded)
High-Speed Counter	6 high-speed counters
Pulse Output	2 (embedded)
Ethernet Port	Yes
