Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 299
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
The object group of the Device Attribute object is 0. The supported range of the
variation is 211…255.
The R/W property shows if the object is Read Only, Read, or Write. If the R/W
property is writable, the value which was written by DNP3 master device is stored
to non-volatile memory.
The object group of the Device Attribute is 0. The supported range of the
variation is 211…255.
Object Group 0, Variations for Attribute Set 0
Variation Read
/Write
Attribute
Data Type
Length in
Bytes
(Series A)
Max Length
in Bytes
(Series B)
Description Value (Series A) Value (Series B)
211 Read Only VSTR 27 0 for DNP3 Identifier of support for
user-specific attributes
Returns the identifier
for user-specific
attributes.
"Rockwell
Automation, Inc., 1"
Returns the identifier
for user-specific
attributes.
"", NULL for DNP3.
212 Read Only UINT 4 2 Number of master-defined
data set prototypes
00
213 Read Only UINT 4 2 Number of
outstation-defined data set
prototypes
0 The configured
number in the DNP3
Slave Application
Layer Configuration
file.
10, max
214 Read Only UINT 4 2 Number of master-defined
data sets
00
215 Read Only UINT 4 2 Number of
outstation-defined data sets
0 The configured
number in the DNP3
Slave Application
Layer Configuration
file.
10, max
216 Read Only UINT 4 2 Max number of binary
outputs per request
10 10
217 Read Only UINT 4 2 Local timing accuracy 10,000 in microseconds
218 Read Only UINT 4 2 Duration of timing accuracy 0 in seconds
219 Read Only INT 1 1 Support for analog output
events
00
220 Read Only UINT 4 2 Max analog output index 256*3
221 Read Only UINT 4 2 Number of analog outputs 0…256*3
222 Read Only INT 1 1 Support for binary output
events
0
223 Read Only UINT 4 2 Max binary output index 256*16
224 Read Only UINT 4 2 Number of binary outputs 0…256*16
225 Read Only INT 1 1 Support for frozen counter
events
1
226 Read Only INT 1 1 Support for frozen counters 1
