328 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015

Appendix F MicroLogix 1400 Distributed Network Protocol (DNP3)

20 Counter for Commands Received UDP Datagram - Link Layer Diagnostics for DNP3 UDP.

21 Counter for Commands Received with Error

22 Counter for Replies Sent

23 Reserved

24 Reserved

25 Reserved

26 Error Count in sessions

27 Error Code in sessions*

28 Number of Sockets in use

29 Maximum Sockets Allowed

30 Reserved

31 Reserved

32 Counter for Replies Received

33 Reserved

34 Reserved

35 Reserved

36 Reserved

37 Reserved

38 Reserved

39 Reserved

Data File for Troubleshooting

Word Offset Description Category

Other manuals for Allen-Bradley MicroLogix 1400

Questions and Answers:

Need help?

Do you have a question about the Allen-Bradley MicroLogix 1400 and is the answer not in the manual?

General

Processor	32-bit
Expansion Modules	Up to 7 expansion I/O modules
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Communication Ports	Ethernet, RS-232/RS-485 combo port
Controller Type	Programmable Logic Controller (PLC)
Series	MicroLogix
Digital Outputs	12
Analog Inputs	6 (embedded)
Analog Outputs	2 (embedded)
High-Speed Counter	6 high-speed counters
Pulse Output	2 (embedded)
Ethernet Port	Yes
