MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F

40 Counter for Commands Sent TCP Client - Link Layer Diagnostics for DNP3 TCP

Client.

41 Reserved

42 Counter for Replies Received

43 Counter for Replies Received with Error

44 Counter for Replies Timed Out

45 Reserved

46 Error Count in sessions

47 Error Code in sessions*

48 Outgoing Message Connections

49 Maximum Connections Allowed

50 Counter for Commands Received

51 Reserved

52 Counter for Replies Transmitted

53 Reserved

54 Reserved

55 Reserved

56 Reserved

57 Reserved, Firmware use only

58 Reserved, Firmware use only

59 Reserved, Firmware use only

Data File for Troubleshooting

Word Offset Description Category
