Allen-Bradley MicroLogix 1400 User Manual

330 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Appendix F MicroLogix 1400 Distributed Network Protocol (DNP3)
60 Application Layer Error Codes:
0: NO_ERROR - No error found in the Application Layer.
1: FC_CANNOT_BROADCAST - Reserved
2: FC_NOT_SUPPORTED - The received packet has unsupported
Function Code.
3: OBJ_NOT_SUPPORTED - The received packet has unsupported
object(s).
4: BAD_REQUEST_LENGTH - Reserved
5: CONFIGURATION_ERROR - The error was caused by the invalid
configuration during packet generating. E.g. invalid Data Set
Configuration.
6: BAD_PARAMETER - The received packet has invalid parameters
except Function Code and Object Codes. E.g. invalid Qualifier codes.
7: BAD_FILE_TYPE - The error was caused by invalid configuration in
DNP3 Slave Application Layer. Invalid File Type specified.
8: BAD_FILE_NUMBER - The error was caused by invalid
configuration in DNP3 Slave Application Layer. Invalid File Number
specified.
9: BAD_DNP3_ADDRESS - The error was caused by invalid
configuration in DNP3 Slave Application Layer. Invalid File Number
specified.
10: TABLE_WRITE_PROTECTED - The specified DNP3 object data file
has been locked to be written.
11: TABLE_ACCESS_DENIED - The specified DNP3 object data file
has been locked to be read or written.
12: TABLE_OWNERSHIP_ERROR - The specified DNP3 object data
file has been locked to be read or written.
If an error code is within 6 to 12, related file number and element
number are shown in word 64 and 65.
DNP3 Slave - Application Layer Diagnostics for DNP3
Slave.
61 Application Layer Error Count
62 Function Code that caused the last error
63 Last Transmitted IIN in the response
64 Data file number of last error request
65 Data element number of last error request
66 Received Confirm Function Code Counter
67 Received Read Function Code Counter
68 Received Write Function Code Counter
69 Received Function Code Counter other than Confirm, Read and Write
Function Codes.
70 Transmitted Solicited Response Function Code Counter
71 Transmitted Unsolicited Response Function Code Counter
72 Number of events to be reported.
Data File for Troubleshooting
Word Offset Description Category
