Allen-Bradley MicroLogix 1400 User Manual

340 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Appendix F MicroLogix 1400 Distributed Network Protocol (DNP3)
21 10 Frozen Counter - 16-bit
without flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
22 0 Counter Event - Any
Variation
1 (read) 06 (no range, or all)
07, 08 (limited qty)
22 1 Counter Event - 32-bit
with flag
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
22 2 Counter Event - 16-bit
with flag
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 0 Frozen Counter Event -
Any Variation
1 (read) 06 (no range, or all)
07, 08 (limited qty)
23 1 Frozen Counter Event -
32-bit with flag
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 2 Frozen Counter Event -
16-bit with flag
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 5 Frozen Counter Event -
32-bit with flag and time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 6 Frozen Counter Event -
16-bit with flag and time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
30 0 Analog Input - Any
Variation
1 (read) 06 (no range, or all)
30 1 Analog Input - 32-bit with
flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
30 2 Analog Input - 16-bit with
flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
30 3 Analog Input - 32-bit
without flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
30 4 Analog Input - 16-bit
without flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
30 5 Analog Input - Single-prec
flt-pt with flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
32 0 Analog Input Event - Any
Variation
1 (read) 06 (no range, or all)
07, 08 (limited qty)
32 1 Analog Input Event -
32-bit without time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 2 Analog Input Event -
16-bit without time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 3 Analog Input Event -
32-bit with time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 4 Analog Input Event -
16-bit with time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 5 Analog Input Event -
Single-prec flt-pt without
time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 7 Analog Input Event -
Single-prec flt-pt with
time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
Implementation Table for Series A controllers
DNP Object Group & Variation Request
DNP3 Master may issue
MicroLogix 1400 must parse
Response
DNP3 Master must parse
MicroLogix 1400 may issue
Group
Num
Var Num Description Function Codes
(dec)
Qualifier Codes
(hex)
Function Codes
(dec)
Qualifier Codes
(hex)
