Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 341
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
40 0 Analog Output Status -
Any Variation
1 (read) 06 (no range, or all)
40 1 Analog Output Status -
32-bit with flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
40 2 Analog Output Status -
16-bit with flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
40 3 Analog Output Status -
Single-prec flt-pt with flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
41 1 Analog Output - 32-bit 3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 28 (index) 129 (response) echo of request
41 2 Analog Output - 16-bit 3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 28 (index) 129 (response) echo of request
41 3 Analog Output -
Single-prec flt-pt
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 28 (index) 129 (response) echo of request
50 1 Time and Date - Absolute
time
1 (read) 07 (limited qty = 1) 129 (response) 07 (limited qty)
(qty = 1)
2 (write) 07 (limited qty = 1)
50 3 Time and Date - Absolute
time at last recorded time
51 1 Time and Date CTO -
Absolute time,
synchronized
129 (response)
130 (unsol. resp)
07 (limited qty)
(qty = 1)
51 2 Time and Date CTO -
Absolute time,
unsynchronized
129 (response)
130 (unsol. resp)
07 (limited qty)
(qty = 1)
52 1 Time Delay - Coarse 129 (response) 07 (limited qty)
(qty = 1)
52 2 Time Delay - Fine 129 (response) 07 (limited qty)
(qty = 1)
60 1 Class Objects - Class 0
data
1 (read) 06 (no range, or all)
60 2 Class Objects - Class 1
data
1 (read) 06 (no range, or all)
07, 08 (limited qty)
20 (enbl. unsol.)
21 (dab. unsol.)
06 (no range, or all)
60 3 Class Objects - Class 2
data
1 (read) 06 (no range, or all)
07, 08 (limited qty)
60 4 Class Objects - Class 3
data
1 (read) 06 (no range, or all)
07, 08 (limited qty)
20 (enbl. unsol.)
21 (dab. unsol.)
06 (no range, or all)
Implementation Table for Series A controllers
DNP Object Group & Variation Request
DNP3 Master may issue
MicroLogix 1400 must parse
Response
DNP3 Master must parse
MicroLogix 1400 may issue
Group
Num
Var Num Description Function Codes
(dec)
Qualifier Codes
(hex)
Function Codes
(dec)
Qualifier Codes
(hex)
