Allen-Bradley MicroLogix 1400 User Manual

Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 345
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
23 1 Frozen Counter Event - 32-bit
with flag
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 2 Frozen Counter Event - 16-bit
with flag
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 5 Frozen Counter Event - 32-bit
with flag and time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 6 Frozen Counter Event - 16-bit
with flag and time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
30 0 Analog Input - Any Variation 1 (read) 00, 01 (start-stop)
06 (no range, or all)
30 1 Analog Input - 32-bit with flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
30 2 Analog Input - 16-bit with flag 1 (read) 00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
30 3 Analog Input - 32-bit without
flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
30 4 Analog Input - 16-bit without
flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
30 5 Analog Input - Single-prec flt-pt
with flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
32 0 Analog Input Event - Any
Variation
1 (read) 06 (no range, or all)
07, 08 (limited qty)
32 1 Analog Input Event - 32-bit
without time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 2 Analog Input Event - 16-bit
without time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 3 Analog Input Event - 32-bit with
time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 4 Analog Input Event - 16-bit with
time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 5 Analog Input Event - Single-prec
flt-pt without time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 7 Analog Input Event - Single-prec
flt-pt with time
1 (read) 06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
40 0 Analog Output Status - Any
Variation
1 (read)
00, 01 (start-stop)
06 (no range, or all)
40 1 Analog Output Status - 32-bit
with flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
40 2 Analog Output Status - 16-bit
with flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
40 3 Analog Output Status -
Single-prec flt-pt with flag
1 (read) 00, 01 (start-stop)
06 (no range, or all)
129 (response) 00, 01 (start-stop)
