Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 57

Wire Your Controller Chapter 3

1762-OF4 Wiring

I out 0

I out 1

V out 2

V out 3

V out 0

V out 1

COM

I out 3

I out 2

COM

Current Load

Voltage Load
