Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 79

Communication Connections Chapter 4

1761-CBL-PM02 Series C (or equivalent) Cable Wiring Diagram

(1)

External power supply required unless the AIC+ is powered by the device connected to port 2, then the selection switch should be set to cable.

687

44605

Programming

Device

Controller

9-Pin D-Shell 8-Pin Mini Din

9RI B(+)1

8CTS GND2

7RTS RTS3

6 DSR RXD 4

5GND DCD5

4DTR CTS6

3TXD TXD7

2RXD A(-)8

1DCD
