Allen-Bradley PowerFlex 40 User Manual

184 Publication IASIMP-QS001C-EN-P - October 2009
Chapter 13 Create a PowerFlex 40 Application
5. At the O.Start tag, enter 1.
The drive begins to run and the display will
register the drive’s speed until it reaches 55.5
Hz.
6. After the drive has reached 55.5 Hz,
enter 0 at the O.Start tag.
7. At the O.Stop tag, enter 1.
The drive begins to slow until reaching 0.0 Hz.
8. When the drive reaches 0.0 Hz, enter 0 at the
O.Stop tag.
9. Select Go Offline.
By starting and stopping the drive, you verified that:
• the controller is correctly communicating with the drive.
• the drive can receive simple commands.
If you are using EtherNet/IP or ControlNet, you are done configuring the PowerFlex 40
drive and you can continue with the next chapter; or see page 187
for more information.
WARNING
If there is a motor attached to your drive, completing the next
step will cause it to turn.

Allen-Bradley PowerFlex 40 Specifications

General

Output Voltage	0 to Input Voltage
Enclosure	IP20
Control Method	V/Hz, Sensorless Vector Control
Communication	RS485
Frequency	0 to 400 Hz
Protection	Overload, Overvoltage, Undervoltage, Short Circuit
Operating Temperature	-10 to 50°C (14 to 122°F)
Storage Temperature	-40...70 °C (-40...158 °F)
Humidity	5% to 95% non-condensing
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC (depending on model)
