ZA-V BAG0087.11
8.6.1 Replacing the spreading discs
1. Loosen the central bolt with the tool.
2. Remove the spreading disc from the gear-
box shaft.
3. Put on the other spreading disc.
4. For easier assembly, apply assembly paste
(KA059) on the thread of the central bolt.
5. Fasten the spreading disc by tightening the
central bolt.
62
The inner diameter of the spreading
disc and the gearbox attachment are
larger on the right to prevent confusion
of the right and left spreading discs.
63
