Adjustments
ZA
-V BAG0087.11 01.20
103
8.6.2 Adjusting the spreading vane positions
Fig. 64
(1) Short spreading vane
(2) Adjustment scale (5-25) for short spreading vane
(3) Long spreading vane
(4) Adjustment scale (35-55) for long spreading vane
(5) Adjustment lever for spreading vane
(6) Vane locking mechanism as indicator of the vane position
The spreading vane position depends on:
• the working width and
• the type of fertiliser.
• Swivelling the spreading vanes to a higher scale value in
creases
the working width.
• The shorter spreading vanes primarily distribute the fertiliser in
the centre of the spread pattern,
while the longer vanes primarily
distribute it to the outer area.
