-V BAG0087.11 01.20
•
Observe the maximum approved hydraulic operating pressure of
210 bar.
• Check the compatibility of the hydraulic fluids before connecting
the machine to the hydraulic system of your tractor.
• Do not mix any mineral oils with biological oils.
• Slide the hydraulic connector(s) into the hydraulic sleeves until
they are heard to engage.
• Check the coupling points of the hydraulic hose lines for a cor-
rect, tight seat.
• Coupled hydraulic hose lines
ο must easily give way to all movements in bends without
tensioning, kinking or rubbing.
ο must not rub against other parts.
1. Swivel the actuation lever on the control valve on the tractor to
float position (neutral position).
2. Clean the hydraulic plug for the hydraulic hose lines before con-
necting them to the tractor.
3. Couple the hydraulic hose lines with the tractor control units.
5.9.2 Uncoupling the hydraulic hose lines
1. Swivel the actuation lever on the control valve on the tractor to
float position (neutral position).
2. Unlock the hydraulic connectors from the hydraulic sockets.
3. Safeguard the hydraulic sockets against soiling with the dust
protection caps.
4. Insert the hydraulic plug into the plug holder.
