Amazone EasySet 2 User Manual

Structure and function
ZA
-V BAG0087.11 01.20
61
Limiter actuation
Read the value for adjusting the angle of the limiter (0-100) from the
setting chart.
Enter the value for the tilt of the limiter before operation. The value
can be changed during operation.
Lift the limiter for normal spreading /
lower for boundary spreading.
The LED shows when the limiter is lowered.
Lift the limiter higher.
→ Smaller effect of the boundary spreading
deflector.
→ Greater throw distance
Displayed value becomes smaller.
Lower the limiter further down.
→ Greater effect of the boundary spreading
deflector.
→ Smaller throw distance
Displayed value becomes larger.
Fig.
29
Display: value for the tilt of the limiter.
The display switches back to the shutter position
display after 3 seconds.
Fig.
30
If the shutters are opened when the limiter is lowered, a signal tone is
issued. This shows that boundary spreading is active.
Depending on the boundary spreading method, the spread rate must
be reduced on the boundary side.
Read the value for the reduction of the shutter position
from the setting chart.
When keeping the button pressed, the values are scrolled through
rapidly to reach the required value.
