-V BAG0087.11 01.20
The PTO shaft is at its shortest when it is horizontally. The PTO shaft
is at its longest when the machine is fully lifted.
1. Couple the tractor to the machine (do not connect the PTO
shaft).
2. Apply the tractor's parking brake.
3. Determine the clearance height of the machine with the shortest
and longest operating position for the PTO shaft.
3.1 To do so, raise and lower the machine via the tractor's
three-point hydraulic system.
While doing so, ac
tuate the manual controls for the tractor's
three-point hydraulic system on the rear of the tractor, from
the provided workstation.
4. Secure the machine, lifted in the measured clearance height,
against unintentional lowering (for example, by supporting it or
hooking it to a crane).
5. Secure the tractor from unintentional starting before entering the
danger area between the tractor and machine.
6. When measuring the length and shortening the PTO shaft, read
and follow the operating manual from the PTO shaft manufactur-
er.
7. Put the shortened halves of the PTO shaft back together.
8. Grease the universal joint shaft of the tractor and the gearbox
input shaft before connecting the PTO shaft.
The tractor symbol on the protective tube of the PTO shaft identi-
fies the tractor-side connection of the PTO shaft.
