Page 7–6
UPLC-II™ System Manual
Table 7–4.
DNP Binary Outputs – UPLC-II™ Outputs
(ON/OFF Mode)
Point Name Setting Mode Definition
11 General Failure All ON/OFF A Hardware Failure in the UPLC-II™
12 RX Signal Off All ON/OFF Received Level Dropped Below Fade Alarm
Setting (Active Unless Block Signal Received)
13 TX Refl Pwr Alarm All ON/OFF % Reflected Power has Exceeded
Alarm Threshold Setting
14 RX Block Out All ON/OFF Carrier Block Output has Occurred
from the UPLC™
15 RX Carrier Out All ON/OFF Carrier Receive Output has Occurred
from the UPLC™
16 TX Main RF On All ON/OFF TX Level on Main Power Amp
Above 0.5W
17 TX Redundant RF On All ON/OFF TX Level on Redundant Power Amp
If Present Above 0.5W
18 Main PA Alarm All ON/OFF Main Power Amp has Failed
19 Redundant PA Alarm All ON/OFF Redundant Power Amp has Failed
If Present
20 Main PS Alarm All ON/OFF Main Power Supply has Failed
21 Redundant PS Alarm All ON/OFF Redundant Power Supply has Failed
If Present
22 CB Major Alarm If CB Option Checkback Major Alarm Occurred due to
Present Failure of High Level Checkback Test
23 CB Minor Alarm If CB Option Checkback Minor Alarm Occurred due to
Present Failure of Low Level Checkback Test
24 CB Delayed Alarm If CB Option Checkback Delayed Alarm Occured due to
Present Failure to Exit Recovery Mode
25 CB Test Passed If CB Option Successful Checkback Test
Present
26 CB Test in Progress If CB Option Checkback Test in Progress
Present
27 CB in Recovery If CB Option UPLC-II™ Failed Checkback Test
Present and is In Recovery Mode
28 CB Recovered If CB Option UPLC-II™ Successfully Recovered from a CB
Present Test Failure, No Delayed Alarm
29 Auto CB Tests Off If CB Option Automatic Checkback Tests
Present Have Been Turned Off
To Next Page
