Page 2–26
UPLC-II™ System Manual
Table 2–12. Channel: ON/OFF, function: Directional or Phase Comparison Relaying w/Stop
Priority
START STOP LOW LEVEL CB TEST TX OUTPUT CONDITION FOR THIS
KEY INITIATE KEYING INPUT STATE
Not Activated Not Activated Not Activated Not Activated Input States not Likely to Exist
Not Activated Not Activated Not Activated Activated Input States not Likely to Exist
Not Activated Not Activated Activated Not Activated Input States not Likely to Exist
Not Activated Not Activated Activated Activated Input States not Likely to Exist
Not Activated Activated Not Activated Not Activated TX Off, CB Not Allowed
Not Activated Activated Not Activated Activated TX Off, CB Not Allowed
Not Activated Activated Activated Not Activated TX Off, CB Not Allowed
Not Activated Activated Activated Activated TX Off, CB Not Allowed
Activated Not Activated Not Activated Not Activated Send High Output Power, CB Not Allowed
Activated Not Activated Not Activated Activated Send High Output Power, CB Not Allowed
Activated Not Activated Activated Not Activated Send High Output Power, CB Not Allowed
Activated Not Activated Activated Activated Send High Output Power, CB Not Allowed
Activated Activated Not Activated Not Activated Transmitter Off
Activated Activated Not Activated Activated Transmitter Off, CB Allowed
Activated Activated Activated Not Activated Send Low Level Output, CB Not Allowed
Activated Activated Activated Activated Send Low Level Output, CB Not Allowed
Table 2–13. Channel: ON/OFF, function: Directional Comparison Relaying with KA-4 type EM Relaying System
START STOP LOW LEVEL TX OUTPUT CONDITION FOR THIS KEYING
KEY INPUT STATE
Not Activated Not Activated Not Activated Transmitter off
Not Activated Not Activated Activated Send Low Output Power
Not Activated Activated Not Activated Transmitter off
Not Activated Activated Activated Transmitter off
Activated Not Activated Not Activated Send High Output Power
Activated Not Activated Activated Send High Output Power
Activated Activated Not Activated Transmitter off
Activated Activated Activated Transmitter off
CB = Checkback
