Ametek UPLC-II User Manual

January 2016 Page 2–27
Chapter 2. Product Description
2
TRIP or UB Key TX POWER TX OUTPUT CONDITION FOR THIS KEYING
POWER OFF BOOST (52B) INPUT STATE
Not Activated Not Activated Not Activated Send HF at Low Level Output
Not Activated Not Activated Activated Send HF at High Level Output
Not Activated Activated Not Activated Transmitter Output Power off
Not Activated Activated Activated Transmitter Output Power off
Activated Not Activated Not Activated Send LF at High Level Output
Activated Not Activated Activated Send LF at High Level Output
Activated Activated Not Activated Transmitter Output Power Off
Activated Activated Activated Transmitter Output Power Off
Table 2–14. Channel: FSK, function: 2 Frequency Directional Comparison Relaying
DTT KEY LR KEY TX POWER TX OUTPUT CONDITION FOR THIS
POWER OFF BOOST (52B) KEYING INPUT STATE
Not Activated Not Activated Not Activated Not Activated Send CF at Low Power Output
Not Activated Not Activated Not Activated Activated Send CF at High Power Output
Not Activated Not Activated Activated Not Activated Transmitter Output Power Off
Not Activated Not Activated Activated Activated Transmitter Output Power Off
Not Activated Activated Not Activated Not Activated Send HF at High Power Output
Not Activated Activated Not Activated Activated Send HF at High Power Output
Not Activated Activated Activated Not Activated Transmitter Output Power Off
Not Activated Activated Activated Activated Transmitter Output Power Off
Activated Not Activated Not Activated Not Activated Send LF at High Power Output
Activated Not Activated Not Activated Activated Send LF at High Power Output
Activated Not Activated Activated Not Activated Transmitter Output Power Off
Activated Not Activated Activated Activated Transmitter Output Power Off
Activated Activated Not Activated Not Activated Send LF at High Power Output
Activated Activated Not Activated Activated Send LF at High Power Output
Activated Activated Activated Not Activated Transmitter Output Power Off
Activated Activated Activated Activated Transmitter Output Power Off
Table 2–15. Channel: FSK, function: 3 Frequency, Directional Comparison Relaying
