Enova DGX DXLink™ Fiber Boards, Duplex
102
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
* Dolby Digital and DTS support up to 48kHz, 5.1 channels.
** A list is available of HID devices which have been tested and found to be working well with the latest firmware
(see “DXLink - HID supported Devices” on the DXLink Fiber Receiver’s product page at www.amx.com)
.
AMX reserves the right to modify its products and their specifications without notice.
DXLink Fiber, Duplex – Specifications (continued)
Audio Format Support Dolby TrueHD, Dolby Digital*, DTS-HD Master Audio, DTS*, 2 CH through
8 CH L-PCM
Audio Resolution 16 bit to 24 bit
Audio Sample Rate 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
Local Audio Support Yes, insertion and/or extraction of 2 CH L-PCM selectable by channel
EDID Support • EDID provided by an Enova DGX 8/16/32/64 to connected DXLink Fiber
Transmitter
• EDID is user re-programmable
HDCP Support Yes
• Full matrix HDCP support (includes any input to any or all outputs)
• Key Management System
• AMX HDCP InstaGate Pro
®
Technology
• Key support up to 16 devices per output, independent of source device
USB (HID) Transport Use the Enova DGX Digital Media Switcher in conjunction with DXLink
Transmitters and Receivers (twisted pair and/or fiber). Connect a DXLink
Transmitter to a PC and a DXLink Receiver to a keyboard and mouse; the
system then emulates commands from the Receiver back to the PC.**
CEC Support None
ICSP, TCP/IP, USB, IR, Control
Management
Control distribution is managed by the Enova DGX on-board NetLinx Master
and Ethernet switch.
Fiber Transceiver Type 10G SFP+
Fiber Connector LC Duplex conforming to ANSI TIA/EIA 604-10 (FOCIS 10A)
Fiber Cable Types and Supported Length • Single mode, duplex – 9/125 m @ 6.21 miles (10 km)
• Multimode, duplex – OM3 50/125 m @ 984 ft. (300 m)
Optical Wavelength • Single mode, duplex – 1310 nm
• Multimode, duplex – 850 nm
Single Mode Optical Budget • 7.4 dB (typical) between DXLink Fiber transceivers
• Optical Modulation Amplitude (OMA): -5.2 dBm (min.)
• Optical Modulation Amplitude (OMA) Sensitivity: -12.6 dBm (typical)
Single Mode Optical Transceiver
Mean Output Power
-8.2 dBm to 0.5 dBm (average power)
Multimode Optical Budget • 6.8 dB (typical) between DXLink Fiber transceivers
• Optical Modulation Amplitude (OMA): -4.3 dBm (min.)
• Optical Modulation Amplitude (OMA) Sensitivity: -11.1 dBm (typical)
Multimode Optical Transceiver
Mean Output Power
-1 dBm (average power)
DXLink Fiber Input Board Propagation
Delay
5 s
DXLink Fiber Output Board Propagation
Delay
5 s
Connectors 4 Duplex LC Fiber ports
Safety Certifications Class 1 Eye Safe per requirements of IEC 60825-1 / CDRH
