Product Overview and General Specifications
26
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Enova DGX 32 – General Specifications
* Use the Enova DGX Configuration Tool located at www.amx.com/enova to determine the power requirements of a
configuration and whether any of the DXLink Transmitters or Receivers should be powered with the local power supply to
maintain power supply redundancy in the Enova DGX 32 enclosure.
AMX reserves the right to modify its products and their specifications without notice.
General Specifications
Parameter Value
Approvals UL 60950-1, CSA 60950-1, IEC 60950-1, CE EN 60950-1,
CE EN 55022 Class A, CE EN 55024, FCC CFR Title 47 Part 15
Subpart B Class A, ICES-003 Class A, RoHS, WEEE
AC Power 100 VAC to 240 +/-10% VAC single phase, 50/60 Hz
Power Capacity (max.) 1320 Watts, with redundancy @ 110 VAC
1730 Watts, with redundancy @ 230 VAC
2640 Watts, without redundancy @ 110 VAC
3459 Watts, without redundancy @ 230 VAC
Power Consumption (max.) 1692 Watts*, fully loaded DXLink Power enclosure without redundancy
Power Consumption (typical) 585 Watts, fully loaded HDMI enclosure with redundancy
Thermal Dissipation Full Capacity (max.) 4508 BTU/hr, with redundancy @ 110 VAC
5908 BTU/hr, with redundancy @ 230 VAC
9016 BTU/hr, without redundancy @ 110 VAC
11813 BTU/hr, without redundancy @ 230 VAC
Thermal Dissipation (max.) 5778 BTU/hr*, fully loaded DXLink Power enclosure without
redundancy
Thermal Dissipation (typical) 1998 BTU/hr*, fully loaded HDMI enclosure with redundancy
Power Factor Correction (PFC) Supported, complies with EN60555-2 and EN61000-3-2
Operational Temperature 32° F to 104° F (0° C to 40° C)
Storage Temperature -22° F to 158° F (-30° C to 70° C)
Operational Humidity 5% to 85% RH (non-condensing)
Storage Humidity 0 to 90% RH (non-condensing)
Dimensions 20.08 in. (51 cm) depth; 21.08 in. (53.54 cm) with extractors
19 in. (48.26 cm) width including integral rack mounting ears
10.45 in. (26.54 cm) height (6 RU)
Weight Approximately 73 lb. (33.1 kg) per loaded enclosure
Shipping Weight Approximately 83 lb. (37.6 kg) per loaded enclosure
MTBF 92,000 hrs.
Per Channel Aggregate Data Rate (max.) 12.8 Gbps
Noise Level <54.0 dBA @ 1 m (typical @ 25° C)
Airflow Forced air (inlet on sides; exhaust on back and top)
Compatible DXLink™ Twisted Pair Transmitters
and Receivers
• DXLink Multi-Format Transmitter Modules
• DXLink HDMI Transmitter Modules
• DXLink Multi-Format Wallplate Transmitters
• DXLink Multi-Format Decor Style Wallplate Transmitter (US)
• DXLink HDMI Receiver Modules
Compatible DXLink™ Fiber Transmitters and
Receivers
• DXLink Multi-Format MM Fiber TX, Duplex
• DXLink Multi-Format SM Fiber TX, Duplex
• DXLink HDMI MM Fiber RX, Duplex
• DXLink HDMI SM Fiber RX, Duplex
Compatible DGX Fiber Transmitters and
Receivers
• DGX Fiber DVI Transmitter and Receiver Modules
• DGX Fiber HD-15 Transmitter and Receiver Modules
