Product Overview and General Specifications
28
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Enova DGX – NetLinx and Control Specifications
* Cascaded architecture actual throughput dependent on loading.
Enova DGX 64: Worst case per port throughput is 7 Mbps. Best case is 100 Mbps when used with
64 DXLink Transmitters and 64 DXLink Receivers.
Enova DGX 32: Worst case per port throughput is 10 Mbps. Best case is 100 Mbps when used with
32 DXLink Transmitters and 32 DXLink Receivers.
Enova DGX 16: Worst case per port throughput is 10 Mbps. Best case is 100 Mbps when used with
16 DXLink Transmitters and 16 DXLink Receivers.
Enova DGX 8: Worst case per port throughput is 10 Mbps. Best case is 100 Mbps when used with
8 DXLink Transmitters and 8 DXLink Receivers.
For individual board information and specifications, see the specific board chapter in this manual.
HDMI Input and Output Boards – page 70
DVI Input and Output Boards – page 79
DXLink Twisted Pair Input and Output Boards – page 84
DXLink Fiber Input and Output Boards, Duplex – page 99
SC Optical Input and Output Boards – page 114
Audio Insert/Extract (expansion) Board – page 119
AMX reserves the right to modify its products and their specifications without notice.
NetLinx and Control Specifications
Integrated Controller
LAN/ Ethernet Port NetLinx on-board Master is an NI-3100 Class Controller
• TCP/IP uplink port (LAN 10/100/1000)
• Supports up to 64-port un-managed 10/100 Ethernet Switch*
• Static IP or DHCP/DNS, SSL, Auto-negotiating, Half/Full Duplex,
Auto MDI/MDI-X Crossover
• TCP/IP, UDP/IP, CIP, SMTP, Built-in Web server
• Includes support for DXLink™ devices
• RJ-45 connector
Processor CPU 404 MIPS PowerPC
Memory • SDRAM 256 MB
• NVRAM 1 MB
•Flash 2 GB
Program Port (USB) USB Mini-AB connector (used for NetLinx Studio control)
Enclosure Control
Control Port (Serial) Bidirectional RS-232
• Baud rates of 9600 (default), 19200, 38400, 57600
• DB-9 connector
Control Port (USB) USB Mini-B connector
